IMTRA CORPORATION Windlasses & Rollers Bussmann Type III Class Thermal Circuit Breaker

These Bussmann® breakers are available in 50, 70, 110 & 150 Amps sizes & are offered in surface-mount or thru-bulkhead versions. Thru-bulkhead models include a faceplate & install with a simple 2 1/8″ holesaw cutout. All are IP66 for use in wet locations. Connections are 5/16″ to accept large terminal lugs. All accept input voltage up to 48VDC.

• Switchable/manual reset
• Single lever
• Ignition protected
• Weather proof
• Mounting hole clearance for 5mm or 10-32 screws
• Robust 5/16-18 electrical termination studs in corrosion resistive materials
• Large clearance around studs to accept large gauge wire lugs
• All components meet SAE J1171 ignition protection
• Vapor proof
• Thru-bulkhead with panel & 12 Volts LED indicator light
• IP66 IP rating
• Voltage: 12 to 48VDC
• Amperage: 150 Amps
• Dimensions: 3 1/4″ x 4 1/2″
• Hole Saw Cutout: 2 1/8″
• Terminals: 5/16″
• Case Material: Thermoset polyester
